HDS J2534 Honda / Acura Interface
J2534 Pass-Thru diagnostic cable for all Honda and Acura vehicles, compatible with the official HDS (Honda Diagnostic System) software.
The J2534 (SAE J2534) protocol is the reprogramming standard mandated by manufacturers. This interface allows the full version of HDS to be used, including flashing and ECU reprogramming, across the entire Honda and Acura range.
ECU programming requires HDS with an active J2534 license.
Package contents
- 1 x HDS J2534 Interface
Warranty
Product guaranteed for 1 year, covers manufacturing and delivery defects.
Connection Type
| Vehicle Interface | Standard 16-pin OBD-II |
| Computer Interface | USB |
| Type | Active J2534 Pass-Thru Interface |
Supported Protocols
| CAN Bus | ISO 15765 |
| K-Line | ISO 9141-2 depending on generation |
| J2534 Pass-Thru | SAE J2534 |
Adapters needed
No adapter required. Direct OBD-II to USB connection.
Compatible vehicles
- Honda Jazz, Civic, Accord, CR-V, HR-V, FR-V, e:Ny1, e:NS1, NSX, Pilot, Ridgeline
- Acura ILX, TLX, MDX, RDX, NSX (all OBD-II generations)
- All Honda / Acura OBD-II vehicles, 1996 to present
Check compatibility with your vehicle via the configurator.
Performable operations
- Read and clear fault codes on all ECUs
- Read real-time data (extended datastream)
- ECU programming and flashing via J2534
- Injector, steering wheel, gearbox learning
- Calibration of Honda Sensing systems (ADAS)
- Specific Honda resets
Compatible software
- Honda HDS (Honda Diagnostic System): official diagnostic
- Compatible J2534 software
Software is not included at the time of purchase but can be downloaded free of charge via the links in the software section.
